There are two methods for installing a Bluetooth car kit: one is more challenging than the other (but both can be challenging, depending on the vehicle). Unfortunately, Bluetooth kits often only support ISO connections. For example, ISO is an older industry standard that specifies where to put wiring for things like front and rear speakers and power, mute, and ignition switches. The kits will be simple to install on an ISO-compliant car. To learn about imac pro i7 4k, click here.
The issue is that the ISO standard is getting on in years. CAN bus and fiber optic MOST systems are two examples of technologies used in modern automobiles that dispense with the need for traditional wiring. This necessitates using a mute cable, ISO2CAR, Drive&Mute, or Audio2Car, or splicing into the existing wiring (if possible). They’re all capable of the same work, although their compatibility varies slightly. Audio2Car, for instance, excels in amplified setups.
The routing of the microphone into position is the only other challenging operation involved in installing the Bluetooth kit. This stems from the Bluetooth module’s rear. The typical location for this is behind the car stereo. It would be best to go in the opposite direction of the driver from here. While the process varies by car, removing the glove compartment is usually straightforward once the screws are located.
The fascia of the car’s A-pillar should unclip easily, but if it is screwed in instead, you should be able to access a screw by removing the airbag clip plate (a small plastic clip that indicates the location of the airbag). Before the fascia can be taken off, there may be a few more screws to take out. Installing and routing the cable through the roof’s lining should be possible with a little tug on the rear-view mirror fascia. A metal coat hanger works well for pulling it through (don’t pull too hard, or you’ll break the mirror; mirrors are a headache to replace). From here, run the wire down the A-pillar; however, be careful not to twist it around the airbags. Connect the Bluetooth module to the back of the glove box.
After that, ensure the Power, Ground (if necessary), and Ignition wires are all plugged in and turned on. The kits won’t function without the ignition being tested, so that’s a requirement. This is the most common reason why consumers assume their device is broken. If your harness doesn’t have an ignition switch, the cigarette lighter or the fuse box is a good starting place. Turning on the ignition with the wires attached is a quick and easy way to check everything is working. The device ought to turn on.
Assuming everything is functioning as it should, you should clean up the area behind the stereo, reconnect the dashboard and fascias, and place the microphone where you want it to be in relation to the rearview mirror (without blocking it). Following the manufacturer’s pairing instructions will result in a fully functional Bluetooth car kit. (If you chose correctly, you’d wonder how you ever lived without one).
In most cases, you shouldn’t need more than an hour to complete the task, though some vehicles, such as the BMW X5 (because of the unit’s location) and most Porsches (due to the firewall), may prove more challenging.
If you don’t already have a Bluetooth Car Kit installed, you should get one because it increases driver safety while on the phone. Stay off your phone.
If your car doesn’t already have a Bluetooth Car Kit installed, you should get one because they are known to increase driver safety when using a mobile phone. Stay off your phone. Get in touch with In Car Installer if you feel like you need help with this.
